Access Lite Automatic Sliding Doors | Saint-Gobain Glass Hardware

Access-Lite

Access Lite

Door Parameters

Single Leaf Sliding width

750 - 1400mm

Single Leaf Sliding Weight

1 × 150Kgs

Double Leaf Sliding width

750 - 1250mm

Double Leaf Sliding Weight

2 × 120Kgs

Clear Passage Height

2100 - 3000mm

Technical Details

Mains voltage, frequency

230 V, 50/60 Hz

Power Consumption

65W – BLDC Motor

Opening Speed

15 - 45 cm/s

Closing Speed

15 - 45 cm/s

Hold Open Range

0 - 8 s

Manual Force

<50N

Operating Temperature Range

-20 to +50 °C
